19 Pin Crimp Type Line Female
Stock Code:
KU-PLS-5219CLF
Quantity Breaks
1+
Please Call
Description
19 Pin Crimp Type Line Female
KU-PLS-5219CLF
Features
- Rugged die-casted aluminum alloy shells, with black non-conductive finish, making cable assembly most convenient with two-shell design.
- Hard gold-plated copper alloy machined contact, for both solder and crimp type, ensures the excellent conductibility.
- Non-conductive first grade Bakelite (Neoprene for crimp type) provides greatest insulation.
- Integral-compressed strain relief handles wide range of cable sizes.
- Extended ground contact at female side ensures "mate first, break last" for safety operation.
- Compatible with Socapex "419", Veam "VSC" connectors and LK Connectors.
- Requires PG29 Gland (Not Included)
- Crimp contacts are available for purchase separately.
- UL / cUL listed.
Specification
- Rated Current: AC 20A 250V
- Operating Limit Voltage: AC 400V
- Insulation Resistance: > 2000M Ohms
- Contact Resistance: < 3M Ohms
- Rated Voltage: AC 1500V
- Terminal Wear: 5000+ connection
- Hipot Test: 1800 VAC / Min.
- Operating Temperature: -40Deg to 85Deg
