DMX Decoder 4ch 8A, 12-36VDC, CV, Screw Terminals
Stock Code:
SR-2103BEA
Quantity Breaks
1+
Limited Stock
Description
The SR-2103BEA is a constant voltage DMX512 decoder with 3 channel or 4 channel output selectable and 8A per channel output and available in 12VDC, 24VDC and 36VDC output, which can be switched between DMX decoder mode and stand-alone mode.
- Constant voltage DMX512 decoder with 3 channel or 4 channel output selectable and 8A per channel output, available in 12VDC, 24VDC and 36VDC output
- DMX512 compliant control interface, DMX address can be set freely and shown on the digital numeric display
- Stand-alone mode and DMX512 decoder mode can be freely switched by buttons
- Once under stand-alone mode, the DMX master can adjust brightness of each channel and enter the fading operation mode
- Three-channel / Four-channel output selectable
- To work with power repeater to expand output unlimitedly
